Huawei SFP-10G-USR Overview

The Huawei SFP-10G-USR is a high-performance 10GBASE-USR optical transceiver designed for multi-mode fiber networks. It is ideal for short-distance 10 Gigabit Ethernet (10 GbE) connections in data centers and enterprise environments.

Basic Information

• Part Number: 02310MNW

• Form Factor: SFP+

• Supported Versions: V100R002C00 and later

• Transmission Speed: 10 Gbit/s

• Center Wavelength: 850 nm

• Standards Compliance: 10GBASE-USR

• Connector Type: LC

• Fiber End Face Type: PC or UPC

Applicable Cable & Maximum Transmission Distance

• Multimode Fiber OM2 (50 μm): 30 m

• Multimode Fiber OM3 (50 μm): 100 m

• Multimode Fiber OM4 (50 μm): 150 m

Modal Bandwidth

• OM2: 500 MHz·km

• OM3: 2000 MHz·km

• OM4: 4700 MHz·km

Optical Characteristics

• Transmit Power: -7.3 to -1 dBm

• Receiver Sensitivity: -10.7 dBm

• Overload Power: 0.5 dBm

• Extinction Ratio: ≥ 3 dB

Operating Temperature: 0°C to 70°C
