Overview:
Lock down your network with the Cisco Meraki MX67W cloud-managed security and SD-WAN appliance, featuring 802.11ac Wave 2 Wi-Fi. Designed for small retail branches or clinics, this device supports up to 50 users and delivers stateful firewall throughput of up to 450 Mbps. It can handle up to 50 simultaneous VPN sessions for fully secure data transfer and includes five Gigabit Ethernet interfaces for connecting multiple wired devices.

Because the MX series is entirely cloud-managed, setup and remote administration are effortless. The MX delivers a comprehensive suite of network and security services, including threat management and SD-WAN capabilities, eliminating the need for multiple devices. It allows organizations to deploy and manage retail outlets or branch offices centrally, with minimal on-site configuration.

Product Highlights

• Recommended for small branch networks with up to 50 users

• Up to 600 Mbps of stateful firewall throughput

• Integrated Content Filtering, SNORT® Intrusion Detection/Prevention, and Cisco Advanced Malware Protection (AMP) with the Advanced Security License

• 4 × GbE LAN ports for printers, phones, and other wired devices

• 1 × GbE WAN port, with the option to repurpose a LAN port for failover or load-balanced internet connections

• Integrated wireless with dual-band, dual-concurrent 2.4 GHz & 5 GHz, 2-stream 802.11ac Wave 2 and 802.11n, delivering up to 1.3 Gbps throughput

• Auto VPN for intelligent, secure site-to-site VPN connectivity

• 802.1x port authentication for wired devices

• Layer 7 application traffic shaping and prioritization

• Layer 3 firewall to separate corporate data from personal traffic

• Supports up to 4 SSIDs with integrated enterprise security and guest access

• Self-configuring, plug-and-play deployment

• Compact, small form factor ideal for desktop or wall mounting

Specifications:

• Weight: 2.8 lbs

• Dimensions: 6.5 × 9.4 × 1.1 in

• License Options: SD-WAN Plus, No License, Advanced, Enterprise

• Duration Options: Hardware Only, 1 Year, 3 Years, 5 Years, 7 Years, 10 Years

• Product Description: Cisco Meraki MX67W – Security Appliance

• Device Type: Security appliance

• Form Factor: Desktop

Networking & Connectivity

• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b/a/g/n/ac Wave 2

• Frequency Bands: 2.4 GHz, 5 GHz

• Performance:

  • Firewall throughput: 450 Mbps

  • VPN throughput: 200 Mbps

  • Advanced security throughput: 300 Mbps

• Capacity: Up to 50 users

• Included Accessories: Mounting kit

• Connectivity Technology: Wireless, Wired

• Data Transfer Rate: 1.3 Gbps

• Network / Transport Protocols: IPSec, DHCP

• Routing Protocols: Static IP routing, MPLS

Features:

• Firewall protection

• DHCP and NAT support

• Load balancing and Layer 7 switching

• VLAN support

• Traffic shaping and content filtering

• Intrusion Detection System (IDS) and Intrusion Prevention System (IPS)

• Firmware upgradable

• Wall mountable

• IPSec VPN and Quality of Service (QoS)

• MPLS VPN

• 3G/4G USB Dongle support

• Static routing

• 802.1x authentication

• Link aggregation

• VPN client

• DMZ support

Compliant Standards:
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.11ac Wave 2

Antenna:

• Type: External

• Quantity: 2

Interfaces:

• 4 × 1000Base-T (RJ-45)

• 1 × 1000Base-T (RJ-45) WAN

• 1 × USB 2.0 (Type A)

Cables Included:

• 2 × Network cables

Power:

• Device Type: External power adapter

• Installed Qty: 1

• Max Supported Qty: 1

• Power Provided: 18 Watts

Environment:

• Operating Temperature: 32°F to 113°F (0°C to 45°C)

• Operating Humidity: 5% – 95% (non-condensing)
