The OmniView PRO3 USB and PS/2 KVM Switch delivers reliable and high-performance server control, making it easy for network administrators to manage multiple servers from a single console.

This switch supports monitoring and controlling up to four, eight, or 16 USB- and PS/2-platform servers. PRO Series KVM Switches are ideal for small to medium server rooms, branch offices, and test or development labs.

Designed for scalability, the switch can be daisy-chained using dedicated ports with other OmniView PRO Series or SMB KVM Switches, supporting up to 256 servers. Belkin PRO3 KVM Cables are required for connecting servers and computers.

Technical Specifications

General

• Device Type: KVM switch – 16 ports – stackable

• Enclosure Type: Desktop

• Ports: 16 x KVM port(s)

• Keyboard / Mouse Interface: PS/2

• Max Resolution: 1920 x 1440 @ 75 Hz

• Features: On-Screen Display, firmware upgradable

• Status Indicators: Port status

Expansion / Connectivity

• Interfaces:

  • Keyboard / video / mouse (KVM): 16 x 50 pin Centronics

  • Network stack device: 2 x 25 pin D-Sub (DB-25), 1 x RJ-11 – management

  • Keyboard: 1 x 6 pin mini-DIN (PS/2 style), 1 x 4 pin USB Type A

  • Mouse: 1 x 6 pin mini-DIN (PS/2 style), 1 x 4 pin USB Type A

  • Display / video: 1 x VGA – 15 pin HD D-Sub (HD-15)

Power

• Power Device: External power adapter

Miscellaneous

• Width: 17.2 in / 43.7 cm

• Depth: 7.5 in / 19 cm

• Height: 3.5 in / 8.9 cm

• Weight: 12.1 lbs / 5.5 kg

• Color: Black

• Cables Included: 1 x serial cable

• Rack Mounting Kit: Included

• Manufacturer Selling Program: Belkin B2B

Software / System Requirements

• OS Required: SunSoft Solaris 8, Novell NetWare 5.x, Microsoft DOS 5.x or later, Apple MacOS X, Microsoft Windows Server 2003, Red Hat Linux 8.x, Microsoft Windows 95/98/ME/NT/2000/XP, Microsoft Windows Vista

Manufacturer Warranty

• Service & Support: 3-year limited warranty

Environmental Parameters

• Min Operating Temperature: 32°F / 0°C

• Max Operating Temperature: 104°F / 40°C

• Humidity Range (Operating): 0–80%

Compatibility Information

• Designed For: Belkin OmniView Dual-Rail LCD Console, Titan LCD Rack Console with PRO3
