FEATURES

GIGABIT PERFORMANCE
Minimize transfer times and stream high-bandwidth files to connected devices without interference.

PLUG-AND-PLAY CONVENIENCE
Instantly extend your office network with a quick and easy installation.

QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
Prioritize traffic to particular devices or activities & maintain mission-critical data throughput regardless of network congestion.

AUTO-SENSING PORTS
Automatically optimize speed for each connected device.

TECHNICAL SPECS

Model Name: LGS116

Network Standards:

• IEEE 802.3

• IEEE 802.3u

• IEEE 802.3x

• IEEE 802.3ab

• IEEE 802.3az

Ports: 16 Gigabit Ethernet (10/100/1000) Ports

LEDs: Link, speed, and activity indicators

Performance: Full line rate and forwarding rate of 64B frame at:

• 1.488Mpps for 1000M port

• 0.1488Mpps for 100M port

• 0.01488Mpps for 10M port

MAC Address Table Size: 8K

Bandwidth: 32 Gbps (non-blocking)

Fans: None

Minimum System Requirements: Connected devices need Ethernet connectivity and Ethernet cables

Dimensions (LxWxH): 288 x 102 x 26 mm

Weight: 0.703 kg

Power: 12 VDC, 1 A

Power Consumption: 2.36W/8.01W
Power Consumption: 2.66 W / 9.32 W

Power Saving: Cable connected detection, sleep mode

Power Supply: External

Operating Temperature: 0–50°C

Storage Temperature: -40–70°C

Operating Humidity: 10–90% (non-condensing)

Storage Humidity: 10–90% (non-condensing)

Quality Of Service: 802.1p and DSCP

Regulatory Compliance: FCC Class B, CE

Warranty and Support: 5 Year Warranty
