FEATURES

GIGABIT PERFORMANCE
Minimize transfer times and interference while streaming high-bandwidth files to connected devices.

PLUG-AND-PLAY CONVENIENCE
Instantly extend your office network with a quick and easy installation.

AUTO-SENSING PORTS
Automatically optimize speed for each connected device.

POWER-SAVING FEATURES
The auto power-down feature disables unused ports, and smart power is ideal for short cable runs.

TECHNICAL SPECS

Model Name: LGS108

Network Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3az

Ports: 8 Gigabit Ethernet (10/100/1000) Ports

LEDs: Link and activity indicators

Performance: Full line rate and forwarding rate of 64B frame at:

• 1.488 Mpps for 1000M port

• 0.1488 Mpps for 100M port

• 0.01488 Mpps for 10M port

MAC Address Table Size: 4,000 entries
Bandwidth: 16 Gbps (non-blocking)
Fans: None

Minimum System Requirements: Connected devices need Ethernet connectivity and Ethernet cables.

Dimensions (L × W × H): 168 × 90 × 26 mm
Weight: 0.358 kg

Power: 100–240V AC, 50/60Hz, 5V DC
Power Consumption: 0.997W / 3.355W, 1.07W / 3.53W
Power Input: 12V 0.5A
Power Saving: Cable-connected detection, cable length detection, sleep mode
Power Supply: External

Operating Temperature: 0–50°C
Storage Temperature: -40–70°C
Operating Humidity: 10–90% (non-condensing)
Storage Humidity: 10–90% (non-condensing)

Mounting: Wall

Regulatory Compliance: FCC Class B, CE
Warranty and Support: 5 Year Warranty
