FEATURES

ADVANCED NETWORK MANAGEMENT CAPABILITIES
The Linksys LGS552P switch delivers advanced Layer 2 switching and Layer 3 static routing for seamless VLAN communication without any performance degradation. It efficiently manages internal routing alongside your router and dedicates fixed paths to external traffic and security, ensuring a faster, more reliable network.

INTEGRATED POWER OVER ETHERNET PLUS (POE+)
Simplifies installation by eliminating the need for extra power cables or nearby outlets. Fully backward compatible with the 802.3af (PoE) standard.

ADVANCED TRAFFIC-HANDLING INTELLIGENCE
Layer 2 MAC and Layer 3 IP flow-based policies with rate-limiting control prioritize traffic, making it easy to manage high-bandwidth, real-time voice and video applications without impacting other critical business operations.

ADVANCED NETWORK SECURITY FEATURES
Extensive ACLs block unauthorized users and external attacks. DHCP snooping, IP-MAC-Port binding, and IEEE 802.1X Port Security ensure network integrity. Port authentication and MAC-based port security require clients to verify their identity before transmitting data.

TECHNICAL SPECS

Model Name: LGS552P

Network Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3ae, 802.3x, 802.3ad, 802.3az, 802.1D, 802.1w, 802.1Q/p, 802.1X

Number of Ports with PoE+ Support: 48

Memory: 128 MB

LEDs: System (blue/yellow), Link/Act/PoE (green/green), Max PoE (amber)

System Power Consumption (without PoE+): 110V: 66.63W, 220V: 66.62W

Forwarding Rate: 104.16 Mpps
Switching Capacity: 140 Gbps
MAC Address Table Size: 16K
Jumbo Frame (FE, GE): 9K

Fans: 3 × 8,200 rpm

Dimensions (L × W × H): 440 × 350 × 44.45 mm (17.32 × 13.78 × 1.75 in.)
Weight: 5.32 kg (11.73 lbs.)

Power Dedicated to PoE+: 375W
Power Input: 100–240V, 50–60 Hz (8.4A max)

Operating Temperature: 0 to 50°C (32 to 122°F)
Storage Temperature: -20 to 70°C (-4 to 158°F)
Operating Humidity: 10 to 90% RH
Storage Humidity: 10 to 90% RH (non-condensing)

Spanning Tree: IEEE 802.1d, IEEE 802.1w Rapid Spanning Tree
Link Aggregation: IEEE 802.3ad LACP, up to 4 groups with 8 ports per group

VLAN: Port-based and IEEE 802.1Q tag-based
Auto Voice VLAN: Voice traffic automatically assigned to a voice-specific VLAN with priority treatment
IGMP Snooping: Supports IGMP v1/v2/v3; 256 multicast groups; limits bandwidth-intensive traffic to requesting ports

HOL Blocking Prevention: Yes
Port Mirroring: Mirror traffic from multiple ports for network analysis

Security Features

• IEEE 802.1X radius authentication

• DHCP snooping

• IP-MAC-Port binding

• IP source guard

• ARP inspection

• STP root guard

• STP BPDU guard

• DHCP relay

• Port security (limited dynamic lock and locked MAC addresses)

• Management access control

Storm Control: Broadcast, unknown-unicast, and multicast
Access Control: Supports up to 512 rules for enhanced security or advanced QoS; allows, denies, or rate-limits based on Layer 1–4 protocol fields with MAC ACL and IP ACL

RMON: Embedded remote monitoring for traffic management and analysis

Management Interface

• HTTP

• HTTPS

Other Management: Telnet (menu-driven), DHCP client, system log, configuration unload and backup via HTTP/TFTP, PING, dual images, SNTP
SNMP Support: Version 1, Version 2c

QoS – Class of Service

• Port-based

• IEEE 802.1p priority-based

• IPv4/v6 IP DSCP-based

Combo Ports (RJ45 + SFP): 2 (ports g49, g50)
Copper FE/GE Ports (RJ45): g01–g25, g26–g50
Green Power Mode: EEE+, Short Reach + Energy Detect
QoS Priority Levels: 4 hardware queues
QoS Scheduling: Priority queuing and weighted round robin (WRR)

10Gb Ports (SFP+): XG1, XG2
Total System Ports: 52GE
