FEATURES

ADVANCED NETWORK MANAGEMENT CAPABILITIES
This switch comes equipped with powerful Layer 2 switching and Layer 3 static routing, allowing smooth communication between different VLANs without impacting performance. The Linksys 500 Series handles internal routing on its own, while your router focuses on external traffic and security, resulting in a more organized and efficient network.

INTEGRATED POWER OVER ETHERNET PLUS (PoE+)
With built-in PoE+, installation becomes easier and more cost-effective. Devices can be powered directly through the network cable, eliminating the need for additional electrical wiring or nearby outlets. The switch is also fully backward compatible with the 802.3af (PoE) standard.

ADVANCED TRAFFIC-HANDLING INTELLIGENCE
Traffic prioritization is managed through Layer 2 MAC and Layer 3 IP flow-based policies, along with rate-limiting controls. This ensures high-bandwidth, real-time traffic such as voice and video runs smoothly without slowing down other applications across the network.

ADVANCED NETWORK SECURITY FEATURES
A wide range of security protections keeps your network safe. Access Control Lists (ACLs) restrict unauthorized access and help safeguard against outside attacks. Features like DHCP Snooping, IP and MAC-Port Binding ensure data integrity, while IEEE 802.1X Port Security limits access to approved users only. Port Authentication and MAC-based Port Security add additional layers of verification before any data is allowed through.

TECHNICAL SPECS

Model Name:
LGS528P

Network Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3z
IEEE 802.3ae
IEEE 802.3x
IEEE 802.3ad
IEEE 802.3az
IEEE 802.1D
IEEE 802.1w
IEEE 802.1Q/p
IEEE 802.1X

Number of Ports with PoE+ Support: 24
Memory: 128 MB

LEDs:
System (blue/yellow), Link/Act/PoE (green/green), Max PoE (amber)

System Power Consumption (without PoE+):
110V: 30.73W
220V: 28.88W

Forwarding Rate: 41.67 Mpps
Switching Capacity: 56 Gbps
MAC Address Table: 16K
Jumbo Frame Support: 9K

Fans: Yes (two 8,200 rpm)

Dimensions (L × W × H):
440 × 200 × 44.45 mm (17.32 × 7.87 × 1.75 in.)

Weight:
3.12 kg (6.88 lbs.)

Power Dedicated to PoE+: 192W

Power Input:
100–240V, 50–60 Hz (3.5A max)

Operating Temperature: 0 to 50°C (32 to 122°F)
Storage Temperature: -20 to 70°C (-4 to 158°F)
Operating Humidity: 10 to 90% RH
Storage Humidity: 10 to 90% RH (non-condensing)

Spanning Tree:
IEEE 802.1D Spanning Tree
IEEE 802.1w Rapid Spanning Tree

Link Aggregation:
IEEE 802.3ad LACP, up to 4 groups, up to 8 ports per group

VLAN Support:
Port-based and IEEE 802.1Q tagged VLANs

Auto Voice VLAN:
Automatically identifies and prioritizes voice traffic using OUI recognition.

IGMP Snooping:
Supports IGMP v1/v2/v3
256 multicast groups
Helps manage bandwidth and improves join/leave times.

HOL Blocking Prevention: Yes

Port Mirroring:
Mirror traffic from multiple ports for analysis using a network analyzer.

Security Features

• IEEE 802.1X radius authentication

• DHCP snooping

• IP-MAC-Port binding

• IP source guard

• ARP inspection

• STP root guard

• STP BPDU guard

• DHCP relay

• Port security with limited dynamic lock + locked MAC addresses

• Management access control

Storm Control:
Broadcast, unknown unicast, and multicast protection

Access Control:
Supports up to 512 rules based on Layer 1–4 protocol fields (MAC ACL and IP ACL) for security and QoS policies
Actions include allow, deny, or rate-limit

RMON:
Built-in remote monitoring for enhanced traffic analysis

Management Interface

• HTTP

• HTTPS

Other Management Tools:
Telnet (menu-driven)
DHCP client
System log
Backup/restore via HTTP or TFTP
PING
Dual images
SNTP

SNMP Support:
Version 1
Version 2c

QoS – Class of Service

• Port-based

• IEEE 802.1p priority

• IPv4/IPv6 DSCP-based

Combo Ports (RJ45 + SFP): 2 (ports g27, g28)
Copper FE/GE Ports (RJ45): g01–g13, g14–g26

Green Power Mode:
EEE+, Short Reach, Energy Detect

QoS Priority Levels: 4 hardware queues
QoS Scheduling: Priority queuing and WRR

Total System Ports: 28GE
