FEATURES

ADVANCED NETWORK MANAGEMENT CAPABILITIES
This switch is built for demanding business environments, offering advanced Layer 2 switching and Layer 3 static routing. It can route traffic between different VLANs internally without affecting performance, helping you maintain a smoother and more efficient network. With the Linksys 500 Series, internal routing is handled by the switch itself, freeing your router to manage external traffic and security without bottlenecks.

INTELLIGENT TRAFFIC HANDLING
Designed to keep your network running at peak efficiency, this model supports Layer 2 MAC and Layer 3 IP flow-based policies, along with rate-limiting controls. These features help prioritize high-bandwidth, real-time traffic—such as voice and video—while ensuring your business applications continue to perform reliably.

ROBUST NETWORK SECURITY
To keep your network protected, the switch includes powerful security tools like Access Control Lists (ACLs), which help block unauthorized access and outside attacks. Additional protections such as DHCP Snooping, IP and MAC-Port Binding, and IEEE 802.1X Port Security reinforce network integrity. Port Authentication and MAC-based Port Security ensure that only verified clients can send or receive data on your network.

FIBER-OPTIC EXPANSION OPTIONS
The switch also supports Gigabit SFP+ fiber-optic expansion ports, giving your business room to grow. These ports boost bandwidth, provide redundancy, and support scalability for data-heavy environments such as server farms and data centers. Mini-GIBC expansion ports further extend your options for adding fiber-optic or Gigabit Ethernet uplinks.

TECHNICAL SPECS

Model Name:
LGS528

Network Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3z
IEEE 802.3ae
IEEE 802.3x
IEEE 802.3ad
IEEE 802.3az
IEEE 802.1D
IEEE 802.1w
IEEE 802.1Q/p
IEEE 802.1X

Memory: 128 MB
LEDs: System (blue/yellow), Link/Act (green)

System Power Consumption (without PoE+):
110V: 19.4W
220V: 19.71W

Forwarding Rate: 41.67 Mpps
Switching Capacity: 56 Gbps
MAC Address Table Size: 16K
Jumbo Frame Support: 9K

Dimensions (L × W × H):
440 × 200 × 44.45 mm (17.32 × 7.87 × 1.75 in.)

Weight:
2.43 kg (5.36 lbs.)

Power Input:
100–240V, 50–60 Hz (0.7A max)

Operating Temperature: 0 to 50°C (32 to 122°F)
Storage Temperature: -20 to 70°C (-4 to 158°F)
Operating Humidity: 10 to 90% RH
Storage Humidity: 10 to 90% RH (non-condensing)

Spanning Tree:
IEEE 802.1D Spanning Tree
IEEE 802.1w Rapid Spanning Tree

Link Aggregation:
IEEE 802.3ad LACP, up to 4 groups with up to 8 ports per group

VLAN Support:
Port-based and IEEE 802.1Q tag-based VLANs

Auto Voice VLAN:
Automatically assigns voice traffic to a voice-specific VLAN with proper handling.

IGMP Snooping:
Supports IGMP v1/v2/v3
256 multicast groups
Provides fast joins and leaves while limiting bandwidth usage.

HOL Blocking Prevention: Yes

Port Mirroring:
Mirror traffic from multiple ports to another port for detailed analysis.

Security Features:

• IEEE 802.1X radius authentication

• DHCP snooping

• IP-MAC-Port binding

• IP source guard

• ARP inspection

• STP root guard

• STP BPDU guard

• DHCP relay

• Port security (dynamic lock and locked MAC)

• Management access control

Storm Control:
Broadcast, unknown-unicast, and multicast protection

Access Control:
Up to 512 rules for security and QoS policies
Supports MAC ACL and IP ACL based on Layer 1–4 header fields (allow/deny/rate limit)

RMON:
Built-in remote monitoring for advanced traffic analysis

Management Interface:
HTTP
HTTPS

Additional Management Tools:
Telnet (menu-driven)
DHCP client
System log
Backup/restore via HTTP or TFTP
PING
Dual images
SNTP

SNMP Support:
Version 1
Version 2c

QoS – Class of Service:
Port-based
IEEE 802.1p priority
IPv4/IPv6 IP DSCP-based

Combo Ports (RJ45 + SFP):
2 combo ports (g27, g28)

Copper FE/GE Ports (RJ45):
g01–g13, g14–g26

Green Technology:
EEE+
Short Reach + Energy Detect

QoS – Priority Levels: 4 hardware queues
QoS – Scheduling: Priority queuing and WRR
Total System Ports: 28GE
