FEATURES

Powerful PoE+ Performance for Business Applications

The Linksys Business LGS326MP PoE+ 26-Port Gigabit Smart Switch is built to deliver dependable, business-class networking. With 384 watts of dedicated PoE+ power, it simplifies installation by allowing your network cables to carry both data and power—no need for separate electrical wiring. This makes it ideal for powering high-demand devices such as surveillance cameras, door access control systems, ProAV equipment, wireless access points, video phones, and more.

Designed for Easy Network Expansion

For growing businesses that rely on multiple switches, this model offers excellent scalability. It supports IEEE 802.1s Multiple Spanning Tree Protocol, helping prevent network-damaging loops and ensuring stable connectivity. High-bandwidth trunks move data efficiently between switches, reducing congestion and improving reliability. With Storm Control, the switch also manages excessive traffic to help maintain uninterrupted service.

Smart QoS for Better Performance

With a robust set of QoS tools, the LGS326MP prioritizes network traffic intelligently. IGMP snooping helps direct multicast traffic only where it’s needed, freeing up bandwidth for the rest of the network. This ensures smooth performance for video streaming, VoIP calls, large file transfers, and other bandwidth-heavy tasks.

Advanced Security to Protect Your Network

Your network stays secure with advanced features such as port authentication, MAC-based port security, DHCP snooping, and IP-MAC binding—all aimed at preventing unauthorized access and maintaining data integrity.

TECHNICAL SPECIFICATIONS

Model

LGS326MP

Ports

• Total System Ports: 26 GE

• Copper FE/GE Ports (RJ45): g01–g12, g13–g24

• Combo Ports (RJ45 + SFP): 2 combo ports on g25, g26

• PoE+ Ports: 24 ports

Hardware

• Memory: 128 MB

• LED Indicators: System (blue), Link/Act/PoE (green/green)

• Fans: Three fans (8,200 rpm each)

• MAC Address Table: 8K

• Jumbo Frames: 9K

Performance

• Power Consumption (without PoE+):

  • 110V: 25.2W

  • 220V: 25.5W

• Switching Capacity: 52 Gbps

• Forwarding Rate: 38.69 Mpps

Size & Weight

• Dimensions: 440 × 200 × 44 mm (17.3 × 7.9 × 1.7 in.)

• Weight: 3.14 kg (6.95 lbs)

Power

• PoE+ Power Budget: 384W

• Power Input: 100–240V, 50–60 Hz (7.5A max)

• Power Saving: EEE+, Short Reach, Energy Detect

Environmental

• Operating Temperature: 0°C to 50°C (32°F to 122°F)

• Storage Temperature: -40°C to 70°C (-40°F to 158°F)

• Operating Humidity: 10%–90% RH

• Storage Humidity: 10%–90% RH (non-condensing)

Networking Features

Spanning Tree Protocols

• IEEE 802.1d Spanning Tree

• IEEE 802.1w Rapid Spanning Tree

• IEEE 802.1s Multiple Spanning Trees

Link Aggregation

• IEEE 802.3ad LACP

• Up to 4 groups, each with up to 8 ports

VLAN Features

• Port-based and 802.1Q tag-based VLANs

• Management VLAN, Guest VLAN

• Dynamic VLAN assignment via Radius (with 802.1X)

• Supports 128 active VLANs (4096 VLAN range)

Auto Voice VLAN

Automatically assigns voice traffic to a dedicated, prioritized VLAN using OUI recognition.

IGMP Snooping

Supports IGMP v1/v2/v3, up to 256 multicast groups, enabling efficient handling of video traffic.Additional Functions

• HOL (Head-of-Line) blocking prevention

• Port mirroring for up to 4 ports

• Storm Control for broadcast, flooding, and multicast

• RMON for enhanced monitoring

Security

• 802.1X Radius authentication

• DHCP snooping

• IP-MAC binding

• Port security with dynamic lock + locked MAC options

• Management access control

Management & Monitoring

Interfaces

• HTTP

• HTTPS

Other Management Tools

• Telnet (menu-driven)

• DHCP client

• System logs

• Config backup/restore via HTTP or TFTP

• PING support

• Dual firmware images

• SNTP

SNMP

• Version 1

• Version 2c

• Version 3

Firmware Upgrades

• Web browser (HTTP/HTTPS)

• TFTP

Warranty & Support

• Most countries: Limited Lifetime Warranty

• France, Germany, Spain: 5-year warranty

• Australia & New Zealand: 2-year warranty
