S5735-L24P4X-A Overview

The Huawei S5735-L24P4X-A is a high-performance gigabit access switch designed for flexible Ethernet networking and advanced Layer 3 routing capabilities. It supports PoE+, multiple VLAN configurations, and Super Virtual Fabric (SVF) for simplified deployment and management.

Key Specifications

Forwarding Performance: 96 Mpps
Switching Capacity: 128 Gbit/s (backplane), 336 Gbit/s (non-blocking)
Fixed Ports: 24 × 10/100/1000Base-T ports, 4 × 10GE SFP+ ports
PoE+ Support: Yes

MAC Features

• Auto-learning and aging of MAC addresses

• Static, dynamic, and blackhole MAC entries

• Packet filtering based on source MAC addresses

• Interface-based MAC learning limitations

VLAN Features

• Supports up to 4094 VLANs

• Guest VLAN and Voice VLAN support

• GVRP and MUX VLAN

• VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports

• VLAN mapping: 1:1 and N:1

IP Routing

• Static routes

• RIP / RIPng

• OSPF / OSPFv3

Super Virtual Fabric (SVF)

• Plug-and-play SVF clients

• Automatic software package and patch deployment to clients

• One-click service configuration delivery

• Independent SVF client operation

Interoperability

• VLAN-Based Spanning Tree (VBST), compatible with PVST, PVST+, and RPVST

• Link-type Negotiation Protocol (LNP), similar to DTP

• VLAN Central Management Protocol (VCMP), similar to VTP
