Key Features & Benefits

High-Speed Wi-Fi Performance: Dual-band radio with speeds up to 1.2 Gbps for better capacity and coverage.

Scalable Deployment: Single Point Setup (controller-less) simplifies multi-AP management without extra hardware.

Flexible Connectivity: One Gigabit Ethernet LAN interface for fast uplink to the wired network.

Business-Class Security: WPA2, 802.1X with RADIUS authentication, rogue AP detection, and secure guest access via captive portal.

Easy Installation: Supports PoE, reducing cabling costs with flexible placement on ceilings, walls, or desktops.

Guest Access Control: Captive portal with customizable roles and rights for visitors.

Optimized Performance: Intelligent QoS prioritizes bandwidth for voice and other mission-critical applications.

Future-Ready: IPv6 support for next-generation networks.

Design: Sleek, compact form factor with multiple internal antennas.

Specifications

General

Placement: Table, Wall, Ceiling

LED Indicators: Yes

Security Slot: Kensington lock support

Dimensions: 135 × 135 × 38 mm

Weight: 350 g

Wireless

Standards: IEEE 802.11ac, 802.11b/g/n, 802.11e, 802.11i

Frequency Bands: 2.4 GHz & 5 GHz (dual-band)

Max Data Rate: 1200 Mbps

User Capacity: Up to 64 users

VLAN Support: Yes

SSID Control: SSID broadcast on/off

Antenna: Internal

Networking & Connectivity

Ethernet LAN: 1 × Gigabit (10/100/1000 Mbps)

Automatic Channel Selection: Supported

QoS Support: Yes

DHCP Client: Yes

Workgroup Bridge Mode: Supported

Power

PoE: IEEE 802.3af supported

Power Options: PoE or local power adapter

Security

Authentication: WPA/WPA2, 802.1X with RADIUS

Encryption: HTTPS, SSID isolation, rogue AP detection

Captive Portal: Customizable guest access

Environmental

Operating Temperature: 0°C – 40°C

Storage Temperature: -20°C – 70°C

Operating Humidity: 10% – 90% (non-condensing)

Management

Firmware Upgradeable: Yes

Setup: Intuitive web-based configuration wizard
