Features & Benefits

Compact SFP+ form factor – industry’s smallest 10G design for maximum density.

Hot-swappable – insert or replace without system downtime.

“Pay-as-you-populate” model – deploy as needed for scalability and cost savings.

Digital Optical Monitoring (DOM/DDMI) – advanced real-time diagnostics.

Optical interoperability – works with 10GBASE XENPAK, X2, and XFP on the same link.

Cisco ID feature – ensures certified and tested compatibility.

Technical Specifications
Optical & Cabling Specs

Type: 10GBASE-SR 850nm MMF

Wavelength: 850 nm

Transmit & Receive Range: 840 – 860 nm

Core Size & Distance:

62.5 µm FDDI (160 MHz·km): 26m

62.5 µm OM1 (200 MHz·km): 33m

50 µm (400 MHz·km): 66m

50 µm OM2 (500 MHz·km): 82m

50 µm OM3 (2000 MHz·km): 300m

50 µm OM4 (4700 MHz·km): 400m

Transmit Power: -7.3 to -1.2 dBm

Receive Power: -9.9 to -1.0 dBm

Connector: LC Duplex

Color Code: Beige

Power & Performance

Data Rate: 10 Gbps

Power Consumption: 1W

Operating Temperature Ranges:

Commercial (COM): 0°C to 70°C

Extended (EXT): -5°C to 85°C

Industrial (IND): -40°C to 85°C

Storage Temperature: -40°C to 85°C

Physical Dimensions

Size (H x W x D): 8.5 x 13.4 x 56.5 mm

Weight: ≤ 75 g

Standards & Compliance

Ethernet Standards: IEEE 802.3ae (10-Gigabit Ethernet)

Optical Standards: GR-20, GR-326, GR-1435

Transport Standards: ITU-T G.709, G.975 (GFEC), G.975.1 (EFEC)

MSA Compliance: SFP+ MSA SFF-8431, SFF-8461

Safety:

Laser Class 1 (21CFR-1040, IEC60825-1)

UL #E116441 Compliant cable jacket

ELV & RoHS compliant

Applications

Data centre interconnects

Enterprise wiring closets

Service provider networks

Short-reach 10G Ethernet deployments
