Specifications

Radios

• 2.4 GHz 802.11b/g/n client access radio

• 5 GHz 802.11a/n/ac client access radio

• 2.4 GHz & 5 GHz dual-band WIDS/WIPS, spectrum analysis, and location analytics radio

• 2.4 GHz Bluetooth radio with Bluetooth Low Energy (BLE) and Beacon support

• Concurrent operation of all four radios

• Maximum aggregate frame rate: 1.9 Gbps

• Supported frequency bands (country-specific restrictions apply):

  • 2.412 – 2.484 GHz

  • 5.150 – 5.250 GHz (UNII-1)

  • 5.250 – 5.350 GHz (UNII-2)

  • 5.470 – 5.600, 5.660 – 5.725 GHz (UNII-2e)

  • 5.725 – 5.825 GHz (UNII-3)

Antenna

• Integrated omni-directional antennas (5 dBi gain at 2.4 GHz, 5.5 dBi gain at 5 GHz)

• Individual antenna elements for each radio

802.11ac Wave 2 and 802.11n Capabilities

• 3×3 multiple input, multiple output (MIMO) with three spatial streams

• SU-MIMO and MU-MIMO support

• Maximal Ratio Combining (MRC) and Beamforming

• 20 and 40 MHz channels (802.11n), 20, 40, and 80 MHz channels (802.11ac)

• Up to 256-QAM modulation on both 2.4 GHz and 5 GHz bands

• Packet aggregation

Power

• Power over Ethernet: 37–57 V (802.3at required; limited functionality with 802.3af)

• Alternative 12 V DC input

• Power consumption: 20W max (802.3at)

• Power over Ethernet injector and DC adapter sold separately

LED Indicators

• Multi-color and multi-function status indicator

Interfaces

• 1× 10/100/1000Base-T Ethernet (RJ45)

• 1× DC power connector (5.5 mm × 2.5 mm, center positive)

Mounting

• All standard mounting hardware included

• Desktop, ceiling, and wall mount capable

• Ceiling tile rail (9/16”, 15/16”, or 1½” flush or recessed rails), assorted cable junction boxes

• Integrated bubble level on mounting cradle for precise horizontal alignment

Physical Security

• Two included security screw options

• Kensington lock hard point

• Concealed mount plate with anti-tamper cable bay

Environment

• Operating temperature: 32°F to 104°F (0°C to 40°C)

• Humidity: 5% to 95% non-condensing

Physical Dimensions

• 10.0” × 6.1” × 1.5” (253.4 mm × 155.8 mm × 37.1 mm), excluding mount plate or desk feet

• Weight: 25 oz (0.7 kg)

Security

• Integrated Layer 7 firewall with mobile device policy management

• Real-time WIDS/WIPS with alerts and automatic rogue AP containment via Air Marshal

• Flexible guest access with device isolation

• VLAN tagging (802.1Q) and IPSec VPN tunneling

• PCI compliance reporting

• WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X

• EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM

• TKIP and AES encryption

• Integration with Enterprise Mobility Management (EMM) and Mobile Device Management (MDM)

Quality of Service (QoS)

• Advanced Power Save (U-APSD)

• WMM Access Categories with DSCP and 802.1p support

• Layer 7 application traffic identification and shaping

Mobility

• PMK and OKC credential support for fast Layer 2 roaming

• Distributed or centralized Layer 3 roaming

Analytics

• Embedded location analytics reporting and device tracking

• Global Layer 7 traffic analytics reporting per network, device, and application
