The OmniView PRO3 USB and PS/2 KVM Switch delivers reliable server control with exceptional performance.

This switch allows network administrators to monitor and manage up to 4, 8, or 16 USB- and PS/2-platform servers from a single console. The PRO Series KVM Switches are widely used in small to medium server rooms, branch offices, and test and development labs.

Designed to scale with your server network, the switch can be daisy-chained with other OmniView PRO Series or SMB KVM Switches via dedicated daisy-chain ports, supporting up to 256 servers. Belkin PRO3 KVM cables are required to connect your servers and computers.

Technical Specifications

General

• Device Type: KVM switch – 8 ports – stackable

• Enclosure Type: Desktop

• Ports: 8 x KVM

• Keyboard / Mouse Interface: PS/2

• Max Resolution: 1920 x 1440 @ 75 Hz

• Features: On-Screen Display, firmware upgradable

• Status Indicators: Port status

Expansion / Connectivity

• Interfaces:

  • Keyboard / video / mouse (KVM): 8 x 50-pin Centronics

  • Network stack device: 2 x 25-pin D-Sub (DB-25)

  • Management: 1 x RJ-11

  • Keyboard: 1 x 6-pin mini-DIN (PS/2), 1 x 4-pin USB Type A

  • Mouse: 1 x 6-pin mini-DIN (PS/2), 1 x 4-pin USB Type A

  • Display / Video: 1 x VGA – 15-pin HD D-Sub (HD-15)

Power

• Power Device: External power adapter

Miscellaneous

• Dimensions (W x D x H): 17.2 x 7.5 x 1.8 in (43.7 x 19 x 4.6 cm)

• Weight: 9.3 lbs / 4.2 kg

• Color: Black

• Cables Included: 1 x serial cable

• Rack Mounting Kit: Included

• Manufacturer Selling Program: Belkin B2B

Software / System Requirements

• OS Required: SunSoft Solaris 8, Novell NetWare 5.x, Microsoft DOS 5.x or later, Apple macOS X, Microsoft Windows Server 2003, Red Hat Linux 8.x, Microsoft Windows 95/98/ME/NT/2000/XP, Microsoft Windows Vista

Manufacturer Warranty

• Service & Support: 3-year limited warranty

Environmental Parameters

• Min Operating Temperature: 32°F / 0°C

• Max Operating Temperature: 104°F / 40°C

• Operating Humidity: 0–80%

Compatibility Information

• Designed For: Belkin OmniView Dual-Rail LCD Console, Titan LCD Rack Console with PRO3
