General

• Authentication Methods: RADIUS, TACACS+

• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.3at

• Device Type: Managed Switch – 6 Ports

• Enclosure Type: DIN Rail-Mountable, Wall-Mountable

• MAC Address Table Size: 4K entries

• Performance: Switching Capacity – 12 Gbps

• Ports: 4 x 10/100/1000 Mbps + 2 x Gigabit SFP

• Remote Management Protocols: SNMP v1/v2c/v3, HTTP, HTTPS, CLI

• Routing Protocol: Static IP Routing

• Subtype: Gigabit Ethernet

Dimensions & Weight

• Width: 15.9 cm

• Depth: 13.4 cm

• Height: 5.5 cm

Environmental Parameters

• Operating Temperature: -40°C to 75°C

• Storage Temperature: -40°C to 85°C

• Operating Humidity: 5% – 95% (non-condensing)

• Storage Humidity: 5% – 95% (non-condensing)

Expansion / Connectivity

• Interfaces:

  • 4 x 1000Base-T – RJ-45

  • 2 x 1000Base-X – SFP

  • 1 x Console – RJ-45

  • 1 x USB – Type A

Miscellaneous

• Certifications & Standards: EN55022, EN55024:2010, EN 61000-4-2/3/4/5/6, UL 60950-1, IEC 60950-1, EN 60950-1, CSA 22.2 No. 60950-1, WEEE, RoHS, China RoHS, IEC 60068-2-6, Directives 2004/108/EC & 2006/95/EC

Power

• Power Device: Internal Power Supply

• Power Consumption: 24W (Operational)

• Input Voltage: DC 12–48V
